Panel Programming

• Engineer Menu 56
• Select External Telecoms Module (Option 5)*
• Select Alarm Reporting (option 2)
• Select Format (Option 1)
• Enter SIA (Option 2)
• Select SIA level 3
• Ensure Trigger 10 is on
• Ensure Trigger 18 is on
• Activate any further triggers which are required
• Select Tel No. 1 (Option 2)
• Set Phone number (01234 567890)
• Select Account Number (Option 3)
• Enter Site ID <_____> (Chip Number)
• Go to Remote Access (Option 3)
• Select Access Period
• Select Mode
• Escape to return to Engineering mode.
• Exit Engineer Mode into Day Mode

Galaxy Troubleshooting

• Menu 23 : Panel Firmware Version
• Menu 62 : Full Set inside Engineering
• Galaxy panels running version V1.4 and below cannot support SIA and are a pins only integration.
• Panel Manufactures Default Codes - USER :1234
• Panel Manufactures Default Codes - ENG :112233

G2 - Specific Programming

• Follow above Panel Programming then complete the below - Galaxy G2 Panels Only
• Select H/W Priority (Option 6)
• 1.Select Telecom [1]
• 2.Select Ethernet [0]
• Use escape to return to Engineer Mode. You need to fully exit Engineering to find the WebWay as a Comms module, we also emulate a Keypad, typically Comms Module 004 and Keypad 015 – varies between panels.
• SPT is running V1.12 or later.

UDL information for this item can be found here:
