Panel Programming

• Login to panel's Engineer mode
• Go to and select PROGRAM ARC/SMS? and then Calls?
• Set ARC/SMS to Enabled’ [0]
• Select ARC Details [1] and set Active to Yes [1]
• Set Format to WebWayOne [141]
• Set SIA Ack Char [006]
• Set SIA Nack Char [021]
• Valid Areas is Engineer’s choice
• Area Accounts is Engineer’s choice
• Set ARC Account to Site ID/Account No
• Set Content [1-32] Engineer’s choice
• Set Redials [03]
• Set Time Out Seconds [30]
• Set Test Calls is Engineer's choice
• Exit Engineer Mode into Day Mode

Remote Access Programming

• Go to ‘Set Up Downloading’
• Select Download by (WebWayOne) [4]
• Select Poll Timeout [10]
• Select Modem Init Tmout [060]
• Select Rings To Answer [1]
• Select Comm Tx Timeout [030]
• Select Comm Dial Tmout [030]
• Select UDL Tx Timeout [02]
• Select ARMPC Tel No, enter 1111
• Select Program PCs [1]
• Modem Tel No, enter 1111
• Select Signal Alarms No [0]
• Select Signal Faults No [0]
• Select Signal Set/Unset No [0]
• Select Signal Access C. No [0]
• Select UDL Password (Optional)
• Exit engineering mode and save the configuration

Limitations

• Panel ARM feature is not supported. Waiting for panel support in Pyronix Insite application.

UDL information for this item can be found here:
